Horizontal shaft 22mm general purpose engine with 2:1 reduction gear & electric starting & centrifugal clutch mounted.

IDEAL FOR: Heavy duty or professional applications such as Karts, pumps, generators, concrete mixers, water blasters etc where slower RPM are required.

• 2:1 reduction gear box for RPM approx 1500-1800 at PTO
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 163 cc capacity 3.6kwatt output (@3,600rpm)
• Max torque 10.8Nm/1.10kg @2,500rpm
• 3.6 litre fuel tank capacity
• 22mm crankshaft with centrifugal clutch
• Electric staring & pull starting backup
• Superb fuel economy with GENUINE HONDA engine technology
• Dimensions (LxWxH) 312x362x335mm

For more information please CONTACT US

Horizontal shaft ¾” general purpose engine with Electric Start.

IDEAL FOR: Domestic or Professional applications such as Karts, pumps, generators, concrete mixers, water blasters etc.

• Electric Start capability (battery not included) also with manual start
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 196 cc capacity 4.1kwatt output (@3,600rpm)
• Max torque 13.2Nm/1.35kg @2,500rpm
• 3.6 litre fuel tank capacity
• Superb fuel economy with GENUINE HONDA engine technology
• 18.0kg dry weight
• Dimensions (LxWxH) 313x376x335mm

For more information please CONTACT US

Horizontal shaft 25mm general purpose engine with 2:1 reduction gearing.

IDEAL FOR: Larger domestic or professional applications such as Karts, pumps, generators, concrete mixers, water blasters etc.

• Reduced gearing 2:1 (1000-1800rpm)
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 270 cc capacity 6.0kwatt output (@3,600rpm)
• Max torque 19.1Nm/1.90kg @2,500rpm
• 6.0 litre fuel tank capacity
• Superb fuel economy with GENUINE HONDA engine technology
• 25.0kg dry weight
• Dimensions (LxWxH) 380x430x410mm

For more information please CONTACT US

Horizontal shaft 1” general purpose engine with Electric Start.

IDEAL FOR: Larger domestic or professional applications such as Karts, pumps, generators, concrete mixers, water blasters etc.

• Electric starting (battery not included)
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 337 cc capacity 7.1 kwatt output (@3,600rpm)
• Max torque 23.5Nm/2.40kg @2,500rpm
• 6.5 litre fuel tank capacity
• Superb fuel economy with GENUINE HONDA engine technology
• 34.0kg dry weight
• Dimensions (LxWxH) 405X450X443mm

For more information please CONTACT US

Genuine Briggs & Stratton Vanguard 16.0hp is a Commercial Grade V-Twin Cylinder general purpose 16.0hp 4 stroke horizontal shaft OHV engine complete with electric starting.

IDEAL FOR: Replacement engine for shredders, tillers, rotary hoes, pumps, generators, concrete mixers, Karts & other applications.

• Model 305447.0126
• 16.0hp  4 stroke (11.94kwatt)
• 480cc (29.3cubic inch) capacity with 1” standard shaft size
• Electric starting
• Large 8.5 litre fuel tank
• Including muffler – will be supplied with “high-mount” muffler unless otherwise specified – for other options contact us
• Weight 34.9kg
• Max.Torque (N-m) 24.4 @2500rpm
• Dimensions: (LxWxH) 324x406x439mm

For more information please CONTACT US

Genuine Briggs & Stratton Vanguard 16.0hp is a Commercial Grade V-Twin Cylinder general purpose 16.0hp 4 stroke horizontal shaft OHV engine complete with electric starting.

IDEAL FOR: Replacement engine for shredders, tillers, rotary hoes, pumps, generators, concrete mixers, Karts & other applications.

• Model 305447.0146-E1
• 16.0hp  4 stroke (11.94kwatt)
• 480cc (29.3cubic inch) capacity with 1” standard shaft size
• Electric starting
• Supplied WITHOUT fuel tank
• Including muffler – will be supplied with “high-mount” muffler unless otherwise specified – for other options contact us
• Weight 33kg
• Max.Torque (N-m) 24.4 @2500rpm
• Dimensions: (LxWxH) 324x406x439mm

For more information please CONTACT US

Horizontal shaft 1” general purpose engine with electric start.

IDEAL FOR: Larger domestic or professional applications such as Karts, pumps, generators, concrete mixers, water blasters etc.

• Electric Starting (battery not included)
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 389 cc capacity 13.0hp output (@3,600rpm)
• Max torque 26.5Nm/2.70kg @2,500rpm
• 6.5 litre fuel tank capacity
• Superb fuel economy with GENUINE HONDA engine technology
• 34.0kg dry weight
• Dimensions (LxWxH) 405X450X443mm

For more information please CONTACT US

Horizontal shaft 1” general purpose V-Twin OHV engine with Electric Start.

IDEAL FOR: Larger professional applications such as Professional water blasters, Stump Grinders, Generators, Hovercraft, and Pumps etc.

• 90 degree V-Twin design
• Electric Starting (battery not included)
• Manual recoil starter available as optional extra
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 614 cc capacity 12.4kwatt output (@3,600rpm)
• Max torque 43.1Nm/4.39kg @2,500rpm
• Supplied with muffler (not fitted) & no fuel tank supplied
• Superb fuel economy with GENUINE HONDA engine technology
• 42.0kg dry weight
• Dimensions (LxWxH) 388x457x452mm

For more information please CONTACT US

Horizontal shaft 1” general purpose V-Twin OHV engine with Electric Start.

IDEAL FOR: Larger professional applications such as Professional water blasters, Stump Grinders, Generators, Hovercraft, and Pumps etc.

• 90 degree V-Twin design
• Electric Starting (battery not included)
• Manual recoil starter available as optional extra
• Cast iron sleeve cylinder with OHV (Over Head Valve)
• 614 cc capacity 13.5kwatt output (@3,600rpm)
• Max torque 44.1Nm/4.50kg @2,500rpm
• Supplied with muffler (not fitted) & no fuel tank supplied
• Superb fuel economy with GENUINE HONDA engine technology
• 42.0kg dry weight
• Dimensions (LxWxH) 388x457x452mm

For more information please CONTACT US

Genuine Briggs & Stratton Vanguard 18.0hp is a Commercial Grade V-Twin Cylinder general purpose 18.0hp 4 stroke horizontal shaft OHV engine complete with electric starting.

IDEAL FOR: Replacement engine for shredders, tillers, rotary hoes, pumps, generators, concrete mixers, Karts & other applications.

• Model 356447.0183
• 18.0hp  4 stroke (13.43kwatt)
• 570cc (34.8cubic inch) capacity
• 1” standard shaft size
• Electric starting
• Large 8.5 litre fuel tank
• Weight 35.9kg
• Max. Torque (N-m) 30.0 @2400rpm
• Dimensions: (LxWxH) 331x406x439mm

For more information please CONTACT US

Genuine Briggs & Stratton Vanguard 20.0hp is a Commercial Grade V-Twin Cylinder general purpose 20.0hp 4 stroke horizontal shaft OHV engine complete with electric starting & now with oil cooler.

IDEAL FOR: Replacement engine for shredders, tillers, rotary hoes, pumps, generators, concrete mixers, Karts & other applications.

• Model 385447.0116
• 20.0hp  4 stroke (14.92kwatt)
• 627cc (38.26cubic inch) capacity 1” standard shaft size
• Electric starting
• Supplied with muffler but no fuel tank
• Weight 35.9kg
• Max.Torque (N-m) 42.1 @2600rpm
• Dimensions: (LxWxH) 421x404x449mm

For more information please CONTACT US

Genuine Briggs & Stratton Vanguard 22.0hp is a Deluxe Commercial Grade V-Twin Cylinder general purpose 22.0hp 4 stroke horizontal shaft OHV engine complete with electric starting & oil cooler

IDEAL FOR: Replacement engine for shredders, tillers, rotary hoes, pumps, generators, concrete mixers, Karts & other applications.

• Model 380447.0171
• 22.0hp  4 stroke (16.4kwatt)
• 627cc (38.26cubic inch) capacity
• 1” standard shaft size
• Electric starting
• Supplied with muffler (various options) but no fuel tank
• Weight 35.9kg
• Max.Torque (N-m) 45.7 @2700rpm
• Dimensions: (LxWxH) 421x404x449mm

For more information please CONTACT US
